Injection molding is a technique for producing a number of identical parts. It functions by forcing hot and melted materials into a mold specifically made for this procedure. This method is responsible for an infinitely high number of plastic products that we use daily.
Imagine a silicone mold that is backed up by a robotic arm. This kind of mold can crank out thousands or even millions of parts with very little deviation from the design. If you’ve ever asked yourself what is injection molding, you will now get the right answer.
You can learn about each stage of this technique with this guide. We will discuss what materials are available and the price involved. We’ll also elucidate if it’s the right choice for your project. Our mission is to provide you with an all-around view of this essential production technique.
Understanding The Injection Molding Process: Step-by-Step Breakdown
The injection molding process is fast and can be done over and over again. A cycle can be just seconds. But it contains several precise steps. Knowing them is the key to understanding injection molding.
This technology gives you the chance to obtain many identical high-quality parts. The molding cycle is started with the major steps of clamping, injection, cooling, and ejection. Each phase requires careful control. Thus, it guarantees that the product will meet all specifications.
-
Clamping
The cycle opens with the mold. A mold is a two-piece that fits into each other. They are mounted on a machine. The clamping device forcibly pushes these two pieces together. At this moment, the mold is kept closed while the hot plastic is injected into it. -
Injection
The small plastic granules enter the machine’s barrel. Hot air creates a liquid from the granules with the help of a giant screw. The screw then injects a certain amount of plastic that is under high pressure. This shot comes after the plastic moves through a nozzle into the empty cavity of the mold. -
Cooling
After the hot plastic has filled the mold, it begins to cool. In the cooling step, the plastic solidifies and gets the shape of the mold. This phase is often the longest part of the cycle. The time required for this process varies with the type of plastic used and the thickness of the part. -
Ejection
Once enough cooling has occurred, the mold opens up. Special pins latch onto the plastic part and push it out of the mold. Before that, they change the closing process of the mold, which is the one undergoing the beginning of a new cycle. The entire process takes place hundreds of times a day, or even thousands.
The Pivot of the Process: Why the Mold is So Critical
The mold is known as tooling. This part stands out as the one most critical and costly in the injection molding process. It is a block made of steel or aluminum and designed on a custom basis. The block is cut to form the exact shape of your part. The quality of the mold directly affects the quality of the final product.
A simple-looking plastic part can need a very complex mold. These tools are more than just blanks. They are complex systems designed for one task.
The main parts included in a mold are:
- Cavity & Core: These are the two halves that give the shape. The cavity refers to the “female” side. The core is the “male” side.
- Runners & Gates: These are channels that carry the hot plastic from the machine’s nozzle to the cavity. The gate is the place where the plastic comes in the part.
- Ejector System: This system, using pins, pushes the finished part out of the mold after it has cooled.
- Cooling Channels: Inside the mold water or oil flows. They are the passages that help control the temperature and speed up the cooling process.
The production of this tool demands a high level of skill. The precision in injection mold making defines the quality and consistency of the final part. Even a minor error within the mold can cause the production of thousands of defective parts.
However, our experience teaches us that a well-executed design results in fewer faulty parts. A well-formed mold also cuts time and material usage, thus a lot of money is saved over a long run. Good tooling is worth the money, this is the right choice for any business.
The Common Materials For Injection Molding
Making parts with injection molding employs many materials. One of the best pros of the method is that a wide variety of materials are available for you to choose from. Materials are of two main types: thermoplastics and thermosets.
Of the two types of materials, thermoplastics are the most used. They are plastics that can exist in the melted state after which they can become solid. The process can then be reversed many times without any changes in the properties. Thermosets are different in that they are subjected to chemical reactions at high temperature and cannot be melted again.
Below are examples of thermoplastics frequently used:
| Material | Key Properties | Common Applications |
|---|---|---|
| ABS | High impact strength, good finish | LEGO bricks, keyboard caps, electronic housings |
| Polycarbonate (PC) | Excellent toughness, transparent, heat resistant | Eyeglass lenses, safety shields, medical devices |
| Polypropylene (PP) | Low cost, chemical resistant, flexible | Food containers, car bumpers, living hinges |
| Nylon (PA) | Strong, durable, good wear resistance | Gears, bearings, zip ties, fabric fibers |
Choosing the right material is crucial for the operation of your part. The issues involved are like: strength, flexibility, heat resistance, and cost.
When to Use Injection Molding?
The making technique you select depends on the project you’re dealing with. Injection molding is powerful, but it is not always the right one. Other methods, such as 3D printing and CNC machining, also have their advantages.
The main parameters to take into consideration are how many parts you need, long-term costs, time frames, and also part complexity. This concept is crucial as a part of what is injection molding, and its inclusion and phase in the making process.
The following comparison will help you in making the choice:
| Factor | Injection Molding | 3D Printing | CNC Machining |
|---|---|---|---|
| Upfront Cost | High | Low | Medium |
| Cost Per Part | Very Low | High | Medium-High |
| Production Volume | Ideal for 10,000+ | Ideal for 1-100 | Ideal for 1-1,000 |
| Material Selection | Vast | Limited | Broad |
| Lead Time | Long initial, then fast | Fast | Medium |
As an illustration, a mold might cost $5,000 or more. However, the per-unit price might drop to below $0.50. For a batch of 50,000 pieces, 3D printing at $5 a part is a great deal more expensive than this process. 3D printing is fine for prototypes including only a few quickly done parts.
In micro-sized quantities of metal or plastic parts with high complexity, China CNC machining services are a better option, ideal for scaling up to molding thereafter. CNC machining, a process that extracts parts from the raw material, offers high precision without the upfront cost of a mold.
Everyday Applications of Injection Molding
As soon as you learn that injection foaming is, everywhere you go, you will begin to realize its presence. The machine manufactures a plethora of products that have become part of our daily lives. This process of injection molding uses its ability to make complex, strong parts at a low cost to make it a monopoly in many sectors.
The following are some of the places you can find injection-molded parts:
- Automotive: Dashboards, bumpers, interior knobs, buttons, and light housings.
- Medical: Syringes, device cases, surgical tools, and testing kits.
- Consumer Electronics: TV remote cases, computer mouse bodies, and power tool housings.
- Packaging: Bottle caps, food and drink containers, and cosmetic jars.
- Consumer Goods: LEGO bricks, toothbrushes, kitchen tools, and furniture parts.
This method of making things stands out because it is flexible and goes in different directions. This production method is capable of yielding parts that range from purely aesthetic to fully functional mechanical by simply changing the design.
Working with Professionals Right from the Start
To have a successful injection molding project, it is not only necessary to have a molding machine. The process is a production plant that requires in-depth knowledge. Working together with this type of partner can be significant in terms of success or failure during a product launch.
The main alteration is the design for manufacturability (DFM). Here, specialists analyze the design of a part in a bid to enhance it for production. Following the rules of thumb of designing for moldability helps avoid common pitfalls. It also enhances the quality of parts and cuts down on costs.
An authority on this matter is helpful throughout the entire process. He will guide you on the choice of suitable materials. This includes the design of the mold and the improvement of process parameters. Such expertise is essential for beginners in the industry.
A collaborative team infused with in-depth knowledge in plastic injection molding ensures that your project runs smoothly. It not only guarantees that the parts you need meet the specifications but also helps you in the early introduction of your product to the market.
To view the online portfolio of our existing services and learn more about how we can help instate your product, visit Mekalite.
FAQ: Answering Your Top Questions About Injection Molding
We have talked very much about injection molding. Below are answers to some more specific questions we often hear.
How long does an injection mold last?
The lifespan of a mold is highly dependent on its material and complexity. An aluminum mold is excellent for prototypes or small runs of 5,000 to 10,000 parts. A P20 steel mold can endure 50,000 to 100,000 cycles. Lastly, for mass production, a hardened H13 steel mold can make over 1,000,000 parts.
What is the difference between injection molding and blow molding?
Injection molding, on the other hand, is creating solid items. Blow molding, on the other hand, is utilized to create hollow objects like bottles and containers. In the process, a tube of plastic (a “parison”) is injected and then put into a different mold and blown up like a balloon to form the final shape.
Can you use metal in injection molding?
Yes, this process is called Metal Injection Molding (MIM). It works by mixing fine metal powders with a binder material to create a feedstock. This feedstock is then molded just like plastic. After molding, the part goes through a process to remove the binder. The metal particles are then joined together, resulting in a dense, solid metal part.
What is a common injection molding defect?
“Sink marks” are typical problems. These are small dips or low spots located on the surface of a part. They are usually caused by uneven cooling. The thick part shrinks by more than its surrounding areas. Good design of part and mold in addition to right processing can prevent sink marks.
What does “shot size” mean in injection molding?
“Shot size” indicates how much plastic can be injected at most by the injection machine at the mold for one cycle. It is a crucial injection molding machine characteristic. It should be compatible with the part size and the mold. Installing a machine with the wrong shot size will most likely result in parts with poor quality.
